[*] posted on 11-9-2007 at 08:47 PM


Courtesy of Chris (Boosted on Austarletclub)

MR2 Spyder front discs from DBA part number DBA753
255mm tall, 20mm disc width, 43.25 overall width, 55mm bore 4 X 100 PCD (http://www.dba.com.au)

Must be used with these calipers & custom mounts, factory calipers will not work:
Wilwood Powerlite 4 piston calipers for use with 20-22mm wide discs, need the 1.38inch bore model.

Levin superstrut brakes very rare and hard to come by check http://www.hardcore.ep91.com. Rory provides pics and the modifications necessary to fit these to the Terc/Seo
View user's profile Visit user's homepage View All Posts By User
Malibuguy
TO Crew
******


Avatar


Posts: 3241
Registered: 16-8-2006
Location: Westminster, MD
Member Is Offline

Mood: Im back...watch the fuck out

[*] posted on 11-9-2007 at 09:58 PM


the corolla rotors would be a nice upgrade, the larger lever-arm would have more braking power, while the increased diameter & width would handle track day heat with ease on a little terc



-Gregory...the exhaust freak & part of the TO.COM (_o_) crew ;)

-97 Whitehawk almost 300k DIS 14lbs 134/174 14.3@95 2.0 60ft. Track day beast. RIP...one day Ill be back

-97 coral rose pearl coupe. Stock with the side of stock
View user's profile Visit user's homepage View All Posts By User
estabon23
TO Crew
******


Avatar


Posts: 2656
Registered: 11-7-2002
Location: Madison, WI
Member Is Offline

Mood: mum is the word

[*] posted on 12-9-2007 at 02:25 AM


& how many/what size piston does the corolla have...?



nothing is true, everything is permissible...
View user's profile View All Posts By User
starletparts
TO Member
**




Posts: 92
Registered: 1-2-2007
Location: Palmerston North, New Zealand
Member Is Offline

Mood: Always here to help ...

[*] posted on 12-9-2007 at 04:12 AM


Three inherent issues exist in the starlet/paseo/tercel braking systems when looking to performance:

- Choice of friction compound on pad
- Choice of brake fluid
- Ability for brake master cylinder to flex off the firewall under heavier braking.

Running huge discs or multi-piston calipers are definitely not required to address the issues above.

You will actually save yourself a lot of coin addressing the fundamentals of braking.

On our track car we aren't running big brake kits or multi-piston calipers yet we still pull up on a dime and outbrake many other cars in our class.

Cheers,

PB.
View user's profile Visit user's homepage View All Posts By User
1991tercelasdf
όber TO Member
*****


Avatar


Posts: 1003
Registered: 19-11-2005
Location: Westminster, MD
Member Is Offline

Mood: shes a squirter

[*] posted on 12-9-2007 at 10:16 AM


the corolla brackets bolt right on, i have pics to prove it.




im back with tercel #7!
'94 tercel
5efte/5spd
megasquirt
aasco flywheel/ACT stage 2 6 puck clutch
STAGG struts w/ Custom rate Ground Control coils
195/50-15 Dunlop Direzza DZ-102 on 15" steelies
View user's profile View All Posts By User
Daox
TO Crew
******


Avatar


Posts: 2614
Registered: 11-7-2002
Location: Milwaukee, WI
Member Is Offline

Mood: No Mood.

[*] posted on 12-9-2007 at 12:09 PM


The brackets bolt up, but what about the discs lining up with the calilpers?



View user's profile Visit user's homepage View All Posts By User This user has MSN Messenger
ugabuga
TO Patron
*******


Avatar


Posts: 5028
Registered: 31-3-2004
Location: Milltown, NJ, USA
Member Is Offline


[*] posted on 12-9-2007 at 12:14 PM


wasnt someone making brake cylinder braces for LHD starlets/paseo/tercel?

i'd like to get one see if it makes a difference.
braided brake lines definitely do.




2004 Mazda Rx-8 (6 speed) - stock
View user's profile View All Posts By User
Malibuguy
TO Crew
******


Avatar


Posts: 3241
Registered: 16-8-2006
Location: Westminster, MD
Member Is Offline

Mood: Im back...watch the fuck out

[*] posted on 12-9-2007 at 12:32 PM


i'm going to try to get austins pics uploaded tonight



-Gregory...the exhaust freak & part of the TO.COM (_o_) crew ;)

-97 Whitehawk almost 300k DIS 14lbs 134/174 14.3@95 2.0 60ft. Track day beast. RIP...one day Ill be back

-97 coral rose pearl coupe. Stock with the side of stock
View user's profile Visit user's homepage View All Posts By User
1991tercelasdf
όber TO Member
*****


Avatar


Posts: 1003
Registered: 19-11-2005
Location: Westminster, MD
Member Is Offline

Mood: shes a squirter

[*] posted on 12-9-2007 at 01:10 PM


i am going to fully install the corolla brakes tonight, and see if there is any clearance issues, but i think they will fit fine.




im back with tercel #7!
'94 tercel
5efte/5spd
megasquirt
aasco flywheel/ACT stage 2 6 puck clutch
STAGG struts w/ Custom rate Ground Control coils
195/50-15 Dunlop Direzza DZ-102 on 15" steelies
View user's profile View All Posts By User
Daox
TO Crew
******


Avatar


Posts: 2614
Registered: 11-7-2002
Location: Milwaukee, WI
Member Is Offline

Mood: No Mood.

[*] posted on 12-9-2007 at 01:22 PM


Quote:
Originally posted by 1991tercelasdf
i am going to fully install the corolla brakes tonight, and see if there is any clearance issues, but i think they will fit fine.


I look forward to it!


Quote:
Originally posted by ugabuga
wasnt someone making brake cylinder braces for LHD starlets/paseo/tercel?

i'd like to get one see if it makes a difference.
braided brake lines definitely do.


To keep it short and not interrupt this thread I'll keep it simple and short. Yeah, I have one made. I fitted it to my Paseo once. It was very nice and enhanced pedal feel a LOT. See the thread here:

http://board.tercelonline.com/viewthread.php?tid=30833

[Edited on 12-9-2007 by Daox]




View user's profile Visit user's homepage View All Posts By User This user has MSN Messenger
josemata16
TO Newbie
*




Posts: 34
Registered: 20-3-2006
Member Is Offline

Mood: No Mood

[*] posted on 12-9-2007 at 07:16 PM


Thanks you all.

So you think that the LHD Tercel/Starlet/Paseo brake master cylinder could handle with the larger calipers without losing capabilities?

Thanks again
Best Regards
View user's profile View All Posts By User This user has MSN Messenger
1991tercelasdf
όber TO Member
*****


Avatar


Posts: 1003
Registered: 19-11-2005
Location: Westminster, MD
Member Is Offline

Mood: shes a squirter

[*] posted on 13-9-2007 at 09:39 AM


this is not a completely direct swap.

the calipers and rotors fit, but the rotors rub somewhere, and i couldn't get a wheel to bolt on, not even the corolla wheel, without hitting the caliper. there is a mounting depth issue between the hub and the caliper bracket, they are too close together.

this weekend i am going to get a complete coroola spindle/hub assembly from the junkyard and see if it will fit.





im back with tercel #7!
'94 tercel
5efte/5spd
megasquirt
aasco flywheel/ACT stage 2 6 puck clutch
STAGG struts w/ Custom rate Ground Control coils
195/50-15 Dunlop Direzza DZ-102 on 15" steelies
View user's profile View All Posts By User
Malibuguy
TO Crew
******


Avatar


Posts: 3241
Registered: 16-8-2006
Location: Westminster, MD
Member Is Offline

Mood: Im back...watch the fuck out

[*] posted on 13-9-2007 at 11:48 AM


the corolla wheel fit fine, the noise you heard was the backside of the rotor scraping on the caliper, like i said last night, the rotor needs to come out a few mm, or maybe the corolla spindle mounts the caliper a hair farther back



-Gregory...the exhaust freak & part of the TO.COM (_o_) crew ;)

-97 Whitehawk almost 300k DIS 14lbs 134/174 14.3@95 2.0 60ft. Track day beast. RIP...one day Ill be back

-97 coral rose pearl coupe. Stock with the side of stock
View user's profile Visit user's homepage View All Posts By User
Daox
TO Crew
******


Avatar


Posts: 2614
Registered: 11-7-2002
Location: Milwaukee, WI
Member Is Offline

Mood: No Mood.

[*] posted on 13-9-2007 at 12:12 PM


What about shimming it out?



View user's profile Visit user's homepage View All Posts By User This user has MSN Messenger
Malibuguy
TO Crew
******


Avatar


Posts: 3241
Registered: 16-8-2006
Location: Westminster, MD
Member Is Offline

Mood: Im back...watch the fuck out

[*] posted on 13-9-2007 at 01:02 PM


we are considering getting a corolla spindle to mess with from the junkyard, so his corolla is not comprimised, & torn completly apart



-Gregory...the exhaust freak & part of the TO.COM (_o_) crew ;)

-97 Whitehawk almost 300k DIS 14lbs 134/174 14.3@95 2.0 60ft. Track day beast. RIP...one day Ill be back

-97 coral rose pearl coupe. Stock with the side of stock
View user's profile Visit user's homepage View All Posts By User
